10ton S-Type Load Cell

Description

10Ton S-Type Load Cell Price in Nigeria



Nature Links Nigeria Limited is an Authorized Distributor, Supplier & Dealer of genuine S-Type Load Cells and weighing equipment in Nigeria, supplying 10-ton S-Type Load Cells, industrial weighing sensors, load cells and weighing-scale components to customers across Nigeria.



10Ton S-Type Load Cell Price in Nigeria



The 10Ton S-Type Load Cell Price in Nigeria depends on the manufacturer, accuracy class, material, protection rating, output signal, availability and whether the load cell comes with accessories or a weighing system.



A 10-ton S-Type load cell is an industrial weighing sensor designed to measure tensile or compressive force and convert the applied load into an electrical signal that can be processed by a weighing indicator or controller.



For the latest 10Ton S-Type Load Cell Price in Nigeria, contact Nature Links Nigeria Limited to confirm the exact model, specifications, warranty and current availability.



10Ton S-Type Load Cell Price Range



The estimated price range for a new 10-ton S-Type load cell in Nigeria is:



₦180,000 – ₦450,000



The actual price can vary according to brand, accuracy, construction material, IP protection, cable length, output characteristics and exchange-rate fluctuations.



Note: Buyers should confirm the exact manufacturer’s datasheet before using this range as a purchasing price because different 10-ton S-Type models can have significantly different specifications.



10Ton S-Type Load Cell Key Features



Typical features of a 10-ton S-Type Load Cell include:



– 10-ton rated capacity

– S-shaped construction

– Measures tension and compression

– Strain-gauge sensing technology

– High measurement accuracy

– Suitable for industrial weighing applications

– Robust metal construction

– Designed for heavy-duty applications

– Compatible with suitable weighing indicators

– Available with different cable lengths

– Low signal output suitable for weighing instrumentation

– Good repeatability when correctly installed

– Suitable for weighing and force-measurement systems

– Available in different accuracy classes and protection ratings



What Is a 10Ton S-Type Load Cell?



An S-Type load cell is a force sensor with an S-shaped body. It is commonly used where the load is applied through tension, although many models can also be configured for compression applications.



The sensor contains strain gauges that respond to mechanical deformation caused by the applied load. The resulting electrical signal is transmitted to a compatible weighing indicator, amplifier or controller.



A 10-ton S-Type Load Cell is therefore suitable for weighing systems where the maximum designed load is around 10 tonnes, provided the complete weighing structure is correctly engineered.



Uses of 10Ton S-Type Load Cell



A 10-ton S-Type load cell can be used in:



– Industrial weighing machines

– Hopper weighing systems

– Tank weighing systems

– Silo weighing systems

– Crane weighing applications

– Suspended weighing systems

– Conveyor weighing systems

– Material handling equipment

– Batching systems

– Force measurement equipment

– Industrial process-control systems

– Heavy-duty platform weighing systems



Benefits of 10Ton S-Type Load Cell



High Load Capacity



A 10-ton capacity makes this type of load cell suitable for many heavy-duty industrial weighing applications.



Tension and Compression Measurement



The S-shaped design allows suitable models to be used for tension applications and, depending on the manufacturer’s specifications, compression measurements.



Good Accuracy



A properly selected and installed load cell can provide accurate measurements for industrial weighing and process-control applications.



Durable Construction



Industrial S-Type load cells are generally built with robust metal bodies designed to withstand demanding operating environments.



Easy System Integration



A compatible load cell can be connected to a weighing indicator, transmitter or PLC-based control system.



Versatile Industrial Application



S-Type load cells can be used across manufacturing, agriculture, logistics, material handling and industrial processing applications.



10Ton S-Type Load Cell Compatibility



Before purchasing, confirm that the load cell is compatible with your weighing system.



Important specifications include:



– Rated capacity

– Excitation voltage

– Output sensitivity

– Accuracy class

– Input resistance

– Output resistance

– Protection rating

– Cable configuration

– Indicator compatibility

– Junction-box requirements

– Mechanical mounting arrangement

– Operating temperature range



The weighing indicator must be capable of accepting the electrical output of the particular load cell.



10Ton S-Type Load Cell Datasheet



Specification| Typical Details

Product Type| S-Type Load Cell

Rated Capacity| 10 Ton

Sensor Technology| Strain Gauge

Measurement| Tension/Compression depending on model

Output| Commonly mV/V

Excitation| Model-dependent

Accuracy| Model-dependent

Construction| Industrial metal alloy/steel depending on model

Protection Rating| Model-dependent

Cable Length| Model-dependent

Operating Temperature| Model-dependent

Application| Industrial weighing and force measurement

Indicator Compatibility| Compatible mV/V weighing indicators

Warranty| Confirm with supplier



Important: These are general specifications. The exact output sensitivity, excitation voltage, accuracy class, IP rating, dimensions and safe overload must be obtained from the manufacturer’s datasheet for the specific 10-ton S-Type load cell.



How Does a 10Ton S-Type Load Cell Work?



When a load is applied to the load cell, its internal strain gauges undergo a small change in resistance. This change creates an electrical signal proportional to the applied force.



The signal is then sent to a weighing indicator or signal-processing device, which converts it into a readable weight measurement.



For accurate measurements, the load cell must be installed correctly and protected against side loads, shock loads, excessive vibration and overload.



10Ton S-Type Load Cell vs Compression Load Cell



Feature| S-Type Load Cell| Compression Load Cell

Shape| S-shaped| Usually cylindrical/button-type

Main Measurement| Tension/compression depending on model| Compression

Suspended Weighing| Excellent| Less suitable

Hopper/Tank Applications| Suitable| Suitable

Mounting| Flexible| Requires compression mounting

Heavy-Duty Use| Yes| Yes

Application Flexibility| High| Application-specific



10Ton S-Type Load Cell vs Other Capacities



Choosing a 10-ton load cell should be based on the maximum expected load and the design of the weighing system.



A load cell should not be selected simply because its rated capacity is larger than the normal operating weight. Engineers should consider maximum load, shock loading, safety factors, environmental conditions and the number of load cells supporting the structure.



For multi-load-cell weighing systems, the total system capacity and load distribution must be properly calculated.



Installation Considerations



For accurate performance, the 10-ton S-Type load cell should be installed according to the manufacturer’s instructions.



Consider:



– Correct mechanical alignment

– Proper mounting hardware

– Protection from side forces

– Protection from excessive vibration

– Proper cable routing

– Correct electrical connections

– Adequate grounding

– Calibration after installation

– Protection against water and corrosive substances where applicable



A qualified weighing-system technician should handle installation and calibration for industrial applications.



Where to Buy 10Ton S-Type Load Cell in Nigeria



If you are searching for 10Ton S-Type Load Cell Price in Nigeria, Nature Links Nigeria Limited can be contacted for current availability, pricing and product specifications.



Distributor, Supplier & Authorized Dealer: Nature Links Nigeria Limited

Call: 07049528019

WhatsApp: 09040054359

Shop Address: F1571 UP, Alaba International Market, Lagos, Nigeria

Delivery: Same-day delivery in Lagos

Shipping: Same-day shipping to other states in Nigeria



Before purchasing, provide the supplier with your required capacity, application, mounting arrangement and weighing-indicator specifications so the correct load cell can be supplied.



What to Check Before Buying a 10Ton S-Type Load Cell



Before paying for a load cell, confirm:



– 10-ton rated capacity

– Brand and model

– Accuracy class

– Output sensitivity

– Excitation voltage

– IP protection rating

– Cable length

– Dimensions

– Mounting requirements

– Safe overload capacity

– Ultimate overload capacity

– Operating temperature

– Warranty

– Availability of replacement units



Why Buy from a Reliable Load Cell Supplier?



A load cell is a precision measurement component, so selecting the correct capacity and specifications is important. Purchasing from a reliable weighing-equipment supplier can help you obtain the appropriate model and technical information for your application.



Nature Links Nigeria Limited can be contacted for product availability, specifications, pricing and delivery arrangements.
