Fluke 1503 Insulation Tester

Key Features of Fluke 1503

Insulation resistance measurement from 0.01 MΩ to 2,000 MΩ
Selectable 500 V and 1,000 V insulation-test voltages
AC/DC voltage measurement up to 600 V
Earth-bond resistance measurement
Low-ohms continuity testing
Live-circuit detection
Auto-discharge of capacitive voltage
Large backlit display
Remote test probe for repetitive and difficult-to-reach testing
Automatic power-off function
CAT IV 600 V safety rating
Compact and rugged handheld construction
Four AA alkaline batteries
Supplied with test leads, test probes, alligator clips, remote probe and holster (Fluke)

Description
Reviews (0)

Description

Fluke 1503 Insulation Tester Price in Nigeria

Nature Links Nigeria Limited is an Authorized Distributor, Supplier & Dealer of genuine Fluke products in Nigeria, supplying Fluke insulation testers, insulation resistance meters, electrical testing instruments, digital multimeters and other Fluke test equipment to customers across Nigeria.

Fluke 1503 Insulation Tester Price in Nigeria

The Fluke 1503 insulation tester Price in Nigeria can vary depending on supplier, exchange rates, product availability, warranty and whether the unit is supplied as brand new or used. For a genuine new Fluke 1503, buyers should budget approximately ₦900,000 – ₦1,400,000 as an indicative Nigerian market range.

The exact selling price should be confirmed with the supplier before ordering because imported electrical testing equipment can experience price changes based on shipping costs and currency fluctuations.

What Is the Fluke 1503 Insulation Tester?

The Fluke 1503 is a compact insulation resistance tester designed for basic residential and commercial electrical insulation testing. It can perform insulation tests from 0.01 MΩ to 2,000 MΩ using 500 V and 1,000 V test voltages. It also measures AC/DC voltage up to 600 V and provides low-ohms earth-bond continuity testing. (Fluke)

Its compact design makes it suitable for electricians and maintenance professionals who need a portable tester for routine electrical testing and troubleshooting.

Fluke 1503 Insulation Tester Uses

The Fluke 1503 can be used for several professional electrical maintenance and testing applications, including:

Electrical insulation testing
Residential electrical installation testing
Commercial electrical maintenance
Motor insulation checks
Cable insulation testing
Electrical troubleshooting
Preventive maintenance
Earth-bond continuity testing
Checking electrical equipment insulation
General electrical commissioning work

Fluke specifically describes the 1503 as suitable for basic residential and commercial insulation testing. (Fluke)

Benefits of Fluke 1503 Insulation Tester

One of the main benefits of the Fluke 1503 is its straightforward approach to insulation testing. It provides the two commonly required test voltages of 500 V and 1,000 V while measuring insulation resistance up to 2,000 MΩ.

The tester also combines insulation testing with AC/DC voltage measurement and earth-bond resistance testing, reducing the need to carry separate instruments for some routine electrical checks.

Its remote probe can make repetitive or hard-to-reach measurements more convenient, while the backlit display helps users read results in different working conditions. (Fluke)

Fluke 1503 Compatibility

The Fluke 1503 is designed for compatible residential, commercial and general electrical testing applications. It can test insulation resistance at 500 V and 1,000 V and measure AC/DC voltage up to 600 V. (Fluke)

Before testing any particular equipment, users should follow the equipment manufacturer’s specifications and applicable electrical safety procedures.

Fluke 1503 Datasheet and Specifications

Specification	Fluke 1503
Product type	Insulation Resistance Tester
Brand	Fluke
Model	1503
Insulation measurement range	0.01 MΩ – 2,000 MΩ
Insulation test voltages	500 V, 1,000 V
AC/DC voltage measurement	Up to 600 V
Earth-bond resistance	0.01 Ω – 20.00 kΩ
Short-circuit current	1 mA nominal for insulation testing
Live-circuit detection	Inhibits test above 30 V
Display	Large backlit display
Safety rating	CAT IV 600 V
Battery	4 × AA alkaline
Battery life	At least 1,000 insulation tests under Fluke’s specified test conditions
Weight	Approximately 550 g
Dimensions	5.0 × 10.0 × 20.3 cm
IP rating	IP40

The specifications above are based on Fluke’s published product data. (Fluke)

Fluke 1503 vs Fluke 1507

The Fluke 1503 and Fluke 1507 have the same general compact form factor, but the 1507 offers more insulation-test voltage options. The 1503 provides 500 V and 1,000 V, while the 1507 adds 50 V, 100 V and 250 V options and extends its insulation measurement capability to 10 GΩ. (Fluke)

For buyers who only need the basic 500 V and 1,000 V insulation tests, the Fluke 1503 can be a practical choice. Buyers requiring more test-voltage flexibility may prefer the Fluke 1507.

Fluke 1503 Insulation Tester Price Range in Nigeria

The estimated Fluke 1503 insulation tester Price in Nigeria is around:

₦900,000 – ₦1,400,000

This is an indicative price range rather than a fixed manufacturer price. The final price may depend on stock availability, exchange rates, shipping, accessories, warranty and supplier terms.

For an accurate current quotation, buyers should contact the supplier directly.

Where to Buy Fluke 1503 Insulation Tester in Nigeria

For customers searching for the Fluke 1503 insulation tester Price in Nigeria, Nature Links Nigeria Limited supplies Fluke electrical testing equipment in Lagos and ships to customers in other parts of Nigeria.

Distributor, Supplier & Authorized Dealer: Nature Links Nigeria Limited
Call: 07049528019
WhatsApp: 09040054359
Shop Address: F1571 UP, Alaba International Market, Lagos, Nigeria
Delivery: Same Day Delivery in Lagos. Same Day Shipping to Other States.

Contact the supplier to confirm the current Fluke 1503 price, availability, accessories and delivery arrangements before purchasing.

Why Choose Fluke 1503?

The Fluke 1503 is designed for electricians and maintenance professionals who need a compact insulation resistance tester for common electrical testing requirements. Its 500 V and 1,000 V test settings, 2,000 MΩ maximum insulation measurement, voltage measurement, earth-bond resistance function and CAT IV 600 V rating make it a versatile instrument for routine professional applications. (Fluke)
