Uni-T Ut673e 2000w Solar MPPT Meter

Name: Uni-T Ut673e 2000w Solar MPPT Meter
Brand: 2000W solar panel tester price Nigeria
Availability: InStock

Original price was: ₦150,000.00.Current price is: ₦100,000.00.

UNI-T UT673E 2000W Solar MPPT Meter Key Features

Maximum power measurement up to 2000W

Maximum power-point voltage measurement

Maximum power-point current measurement

Open-circuit voltage (Voc) measurement

Short-circuit current (Isc) measurement

12–150V Vmp measurement range

5–45A Imp measurement range

12–150V Voc measurement range

5–45A Isc measurement range

0.1W power resolution

0.1V voltage resolution

0.1A current resolution

MC4 test cable connection

Data-hold function

Backlight

Automatic power-off

Reverse-input protection

Over-temperature protection

Portable handheld design

Designed specifically for photovoltaic panel testing

Click to See The Current Price! 🔥

Description
Reviews (0)

Description

UNI-T UT673E 2000W Solar MPPT Meter Price in Nigeria

Nature Links Nigeria Limited is an Authorized Distributor, Supplier & Dealer of genuine UNI-T test instruments in Nigeria, supplying UNI-T solar panel testers, solar MPPT meters, electrical testing equipment and other professional measurement tools to customers across Nigeria.

UNI-T UT673E 2000W Solar MPPT Meter Price in Nigeria

The UNI-T UT673E 2000W Solar MPPT Meter Price in Nigeria varies according to the supplier, product condition, exchange rate, availability and included accessories. Current Nigerian listings show prices around ₦85,000 to ₦140,000, with individual listings at ₦85,000, ₦100,000, ₦120,000 and ₦140,000.

For the latest UNI-T UT673E 2000W Solar MPPT Meter Price in Nigeria, buyers should confirm the current price, authenticity, warranty and package contents with the supplier before payment.

UNI-T UT673E 2000W Solar MPPT Meter Price Range

Current indicative price range: ₦85,000 – ₦140,000

The price can change depending on whether the meter is brand new, the seller’s location, included MC4 accessories, warranty and prevailing market conditions.

UNI-T UT673E 2000W Solar MPPT Meter Key Features

The UNI-T UT673E is a professional photovoltaic panel power tester designed to measure key performance parameters of solar modules. UNI-T’s specifications state that it can measure maximum power from 60W to 2000W, with voltage and current ranges up to 150V and 45A respectively.

Key features include:

– Maximum power measurement up to 2000W

– Maximum power-point voltage measurement

– Maximum power-point current measurement

– Open-circuit voltage (Voc) measurement

– Short-circuit current (Isc) measurement

– 12–150V Vmp measurement range

– 5–45A Imp measurement range

– 12–150V Voc measurement range

– 5–45A Isc measurement range

– 0.1W power resolution

– 0.1V voltage resolution

– 0.1A current resolution

– MC4 test cable connection

– Data-hold function

– Backlight

– Automatic power-off

– Reverse-input protection

– Over-temperature protection

– Portable handheld design

– Designed specifically for photovoltaic panel testing

Uses of UNI-T UT673E 2000W Solar MPPT Meter

The UNI-T UT673E 2000W Solar MPPT Meter Price in Nigeria is particularly relevant to solar installers and technicians who need a portable instrument for testing photovoltaic modules.

It can be used for:

– Testing solar panel output

– Checking maximum power point

– Measuring panel voltage

– Measuring panel current

– Checking open-circuit voltage

– Checking short-circuit current

– Troubleshooting underperforming solar panels

– Comparing solar panel performance

– Solar installation commissioning

– Solar panel maintenance

– Identifying potential PV module problems

– Quality-control checks for photovoltaic modules

UNI-T specifically describes the UT673E as a photovoltaic panel power tester for measuring maximum power, maximum-power voltage/current, open-circuit voltage and short-circuit current.

Benefits of UNI-T UT673E Solar MPPT Meter

Accurate Solar Panel Testing

The instrument provides dedicated measurements for important PV parameters, making it more useful for solar-panel diagnostics than relying solely on a conventional multimeter.

Measures Up to 2000W

Its 60–2000W Pmax range makes it suitable for testing many residential and commercial solar modules within its rated limits.

Portable Design

The UT673E measures approximately 142.5 × 76 × 32 mm and weighs about 230g according to UNI-T’s published specifications, making it convenient for technicians working on different solar installations.

MC4 Connection

The dedicated MC4 test connection makes it convenient for testing compatible photovoltaic panels without relying solely on improvised connections.

Data Hold

The data-hold function allows users to retain measurement readings on the display while carrying out testing and inspection work.

Protection Features

The meter incorporates input protection, including positive/negative reverse protection, while the published specifications also include over-temperature protection.

UNI-T UT673E Compatibility

The UT673E is intended for photovoltaic modules whose electrical output falls within the meter’s specified ranges.

According to UNI-T, the principal measurement ranges are:

– Pmax: 60–2000W

– Vmp: 12–150V

– Imp: 5–45A

– Voc: 12–150V

– Isc: 5–45A

Always check the solar panel’s maximum voltage and current before connecting it to the tester. Do not connect a panel or array whose output exceeds the meter’s rated limits.

UNI-T UT673E 2000W Solar MPPT Meter Datasheet

Specification| UNI-T UT673E

Brand| UNI-T

Model| UT673E

Product Type| Solar PV Power Tester

Maximum Pmax| 2000W

Pmax Range| 60–2000W

Vmp Range| 12–150V

Imp Range| 5–45A

Voc Range| 12–150V

Isc Range| 5–45A

Pmax Resolution| 0.1W

Voltage Resolution| 0.1V

Current Resolution| 0.1A

Pmax Accuracy| ±(1.5% + 5 digits)

Vmp/Imp Accuracy| ±(1.0% + 5 digits)

Voc/Isc Accuracy| ±(1.5% + 5 digits)

Battery| 3 × AAA 1.5V

Auto Power-Off| Approximately 10 minutes

Dimensions| 142.5 × 76 × 32 mm

Weight| Approximately 230g

Test Connection| MC4

Data Hold| Yes

Backlight| Yes

The specifications above are based primarily on UNI-T’s published product information.

What Does the UNI-T UT673E Measure?

The meter measures several important solar-panel parameters:

Pmax: Maximum power output of the tested photovoltaic module.

Vmp: Voltage at the panel’s maximum power point.

Imp: Current at the maximum power point.

Voc: Open-circuit voltage.

Isc: Short-circuit current.

These measurements can help solar technicians assess whether a PV module is performing within expected specifications.

UNI-T UT673E vs Conventional Multimeter

Feature| UNI-T UT673E| Conventional Multimeter

Solar PV Testing| Specifically designed| General-purpose

Maximum Power Measurement| Yes| Usually no direct Pmax function

Vmp Measurement| Yes| Not normally

Imp Measurement| Yes| Depends on meter

Voc Measurement| Yes| Yes

Isc Measurement| Yes| Depends on meter

MC4 Connection| Yes| Usually requires adapters

Solar Troubleshooting| Excellent| Limited

Maximum Rated Power| 2000W| Model-dependent

UNI-T UT673E vs Other Solar Panel Testers

When comparing solar panel testers, consider:

– Maximum test power

– Maximum voltage

– Maximum current

– Measurement accuracy

– MC4 compatibility

– Data storage

– Bluetooth/app connectivity

– Protection features

– Display quality

– Warranty

– Availability of replacement accessories

The UT673E supports up to 2000W, 150V and 45A, while UNI-T’s newer UT673PV+ has a different specification set, including up to 2200W and up to 20A. Therefore, buyers should select the tester based on the electrical characteristics of the PV modules they actually work with.

What Is Included with UNI-T UT673E?

Published documentation lists accessories such as:

– UT673E meter

– MC4 dedicated test cable

– MC4 wrench tool

– AAA batteries

– Warranty/certificate documentation

– Lanyard or carrying accessories, depending on package

Package contents can vary by seller and market, so confirm the exact contents before purchase.

Where to Buy UNI-T UT673E 2000W Solar MPPT Meter in Nigeria

If you are searching for UNI-T UT673E 2000W Solar MPPT Meter Price in Nigeria, contact Nature Links Nigeria Limited for current pricing, availability and delivery.

Distributor, Supplier & Authorized Dealer: Nature Links Nigeria Limited

Call: 07049528019

WhatsApp: 09040054359

Shop Address: F1571 UP, Alaba International Market, Lagos, Nigeria

Delivery: Same-day delivery in Lagos

Shipping: Same-day shipping to other states in Nigeria

Before making payment, confirm the exact UT673E model, product condition, included accessories, warranty and current selling price.

Why Buy UNI-T UT673E from a Reliable Supplier?

A professional solar testing instrument should be purchased from a reliable supplier so that buyers can verify the model, authenticity, accessories and warranty.

For solar technicians, installers and companies, a genuine UT673E can be useful for checking panel performance before installation, during commissioning and when diagnosing an existing PV system.
