SMR Gearbox

Description

SMR Gearbox Price in Nigeria



Nature Links Nigeria Limited is an Authorized Distributor, Supplier & Dealer of genuine SMR gearboxes in Nigeria, supplying SMR shaft-mounted gearboxes, speed reducers, conveyor gearboxes and other industrial power-transmission equipment to customers across Nigeria.



SMR Gearbox Price in Nigeria



The SMR Gearbox Price in Nigeria depends on the gearbox size, model, reduction ratio, output shaft bore, torque capacity, brand, application and current importation and market costs.



SMR is commonly used to describe a shaft-mounted speed reducer/gearbox. SMR gearboxes are widely used for conveyor and other industrial power-transmission applications. Available models commonly range from smaller B/C units through D, E, F, G, H and J sizes, with different output shaft bores and ratios.



For customers searching for the SMR Gearbox Price in Nigeria, it is important to provide the required gearbox size, ratio, motor power, shaft diameter and application when requesting a quotation.



SMR Gearbox Price Range



Based on current international supplier listings, SMR gearboxes can range from roughly US$100 to US$500 or more, depending on size and specification.



After shipping, importation, taxes, dealer margins and other costs are considered, an estimated Nigerian market price range can be:



₦250,000 – ₦2,500,000+



This is an indicative range rather than a fixed Nigerian retail price. Larger SMR models with higher torque capacity and special configurations can cost significantly more.



For the latest SMR Gearbox Price in Nigeria, contact Nature Links Nigeria Limited for a quotation based on your required model and specification.



SMR Gearbox Key Features



Common features of SMR shaft-mounted gearboxes include:



– Shaft-mounted design

– Hollow output shaft

– Helical gear transmission

– Compact construction

– High torque transmission

– Multiple reduction ratios

– Various output shaft bore sizes

– Suitable for conveyor systems

– Torque-arm mounting arrangement

– Strong industrial housing

– Smooth power transmission

– Designed for continuous industrial operation

– Available in different sizes

– Optional backstop on selected configurations



SMR models are available with different output shaft bores. For example, published specifications list B through J models, with standard bore sizes increasing from approximately 30 mm to 100 mm and alternative bore options available depending on the model.



Uses of SMR Gearbox



An SMR gearbox is commonly used where a motor needs to transmit power to a driven shaft at a reduced speed and increased torque.



Typical applications include:



– Belt conveyors

– Mining conveyors

– Quarry equipment

– Cement plants

– Sand-processing equipment

– Grain handling

– Bucket elevators

– Screw conveyors

– Mixers

– Crushers

– Industrial material handling

– Manufacturing equipment

– Packaging machinery

– Agricultural processing equipment



Shaft-mounted speed reducers are particularly associated with conveyor applications because they can be mounted directly onto the driven shaft, reducing the need for some conventional coupling and foundation arrangements.



Benefits of SMR Gearbox



Compact Installation



The shaft-mounted configuration can save installation space compared with some conventional foot-mounted gearbox arrangements.



High Torque Transmission



SMR gearboxes are designed to transmit substantial torque at reduced output speeds, making them suitable for heavy-duty machinery.



Direct Shaft Mounting



The hollow output shaft allows the gearbox to mount directly onto a driven machine shaft in compatible applications.



Smooth Power Transmission



Helical gearing is commonly used in SMR designs to provide smooth and efficient transmission.



Suitable for Conveyors



SMR gearboxes are widely used for belt conveyors and material-handling machinery in industries such as mining, cement, quarrying and grain handling.



Flexible Ratios and Sizes



Different SMR sizes and reduction ratios allow the gearbox to be selected according to motor power, required output speed and torque.



SMR Gearbox Compatibility



Before buying an SMR gearbox, ensure that it matches the motor and driven equipment.



Check the following:



– Motor horsepower

– Motor kW rating

– Motor RPM

– Required output RPM

– Reduction ratio

– Output shaft diameter

– Hollow shaft bore

– Torque requirement

– Conveyor speed

– Conveyor load

– Mounting arrangement

– Torque arm requirements

– Backstop requirements

– Lubrication requirements



For example, published SMR specifications include ratios such as 5:1, 13:1, 15:1 and 20:1, although available ratios vary by manufacturer and model.



SMR Gearbox Datasheet



Specification| Typical Details

Product| SMR Shaft-Mounted Gearbox

Gear Type| Helical

Mounting| Shaft-mounted

Output| Hollow shaft

Application| Industrial power transmission

Common Ratios| 5:1, 13:1, 15:1, 20:1

Model Sizes| B, C, D, E, F, G, H, J

Output Bore| Model-dependent

Input Power| Model-dependent

Output Torque| Model-dependent

Torque Arm| Available/required depending on installation

Backstop| Optional on selected models

Lubrication| Manufacturer/model dependent



Some published SMR specifications cover input power from approximately 0.37 kW to 55 kW and torque ratings from approximately 110 Nm to 7,500 Nm, depending on model and configuration.



Important: Do not use the above figures as a substitute for the manufacturer’s datasheet. The exact specification must be confirmed for the particular SMR gearbox being purchased.



SMR Gearbox Model Sizes



SMR gearboxes are available in different frame sizes. A typical range includes:



SMR Size| Typical Standard Output Bore

SMR-B| 30 mm

SMR-C| 40 mm

SMR-D| 50 mm

SMR-E| 55 mm

SMR-F| 65 mm

SMR-G| 75 mm

SMR-H| 85 mm

SMR-J| 100 mm



Alternative bore sizes may also be available.



SMR Gearbox vs Worm Gearbox



Feature| SMR Gearbox| Worm Gearbox

Design| Shaft-mounted| Usually foot/flange mounted

Output Shaft| Commonly hollow| Solid/hollow depending on model

Typical Application| Conveyors & material handling| General machinery

Gear Type| Helical| Worm and wheel

Torque| High, model-dependent| Model-dependent

Efficiency| Generally high with helical gearing| Often lower at high reduction ratios

Installation| Direct shaft mounting| Conventional mounting

Maintenance| Industrial maintenance required| Industrial maintenance required



SMR Gearbox vs Conventional Gear Reducer



An SMR gearbox is especially useful when the machine’s design permits direct shaft mounting. A conventional gearbox may be preferable where the machine requires a different mounting arrangement, output shaft configuration or coupling system.



The right choice depends on the equipment’s torque, speed, shaft dimensions, mounting requirements and operating environment.



How to Choose the Right SMR Gearbox



To select the correct unit, provide your supplier with:



1. Motor power in HP or kW.

2. Motor speed in RPM.

3. Required output speed.

4. Required reduction ratio.

5. Driven shaft diameter.

6. Required output torque.

7. Conveyor or machine type.

8. Operating hours per day.

9. Starting load.

10. Whether a backstop is required.



Providing these details helps the supplier select an appropriately sized gearbox instead of choosing a model based only on the SMR name.



Where to Buy SMR Gearbox in Nigeria



If you are searching for SMR Gearbox Price in Nigeria, contact Nature Links Nigeria Limited for current pricing, model availability and delivery information.



Distributor, Supplier & Authorized Dealer: Nature Links Nigeria Limited

Call: 07049528019

WhatsApp: 09040054359

Shop Address: F1571 UP, Alaba International Market, Lagos, Nigeria

Delivery: Same-day delivery in Lagos

Shipping: Same-day shipping to other states in Nigeria



When requesting a quotation, provide the motor power, gearbox ratio, shaft diameter, output speed and application so the correct SMR model can be identified.



What to Check Before Buying an SMR Gearbox



Before purchasing, confirm:



– Exact SMR model

– Gearbox ratio

– Input power rating

– Output torque

– Output shaft bore

– Motor speed

– Required output RPM

– Mounting arrangement

– Torque arm

– Backstop

– Lubricant specification

– Warranty

– Availability of replacement parts

– Delivery time
