300kg S-Type Load Cell

Description

300kg S-Type Load Cell Price in Nigeria



Nature Links Nigeria Limited is an Authorized Distributor, Supplier & Dealer of genuine load cells and weighing equipment in Nigeria, supplying 300kg S-Type load cells, industrial weighing sensors, weighing indicators and other weighing-system components to customers across Nigeria.



300kg S-Type Load Cell Price in Nigeria



The 300kg S-Type Load Cell Price in Nigeria depends on the manufacturer, accuracy class, material, protection rating, certification, cable length and current market availability.



A current Nigerian listing advertises a 300kg YZC-516 S-Type Load Cell at ₦55,000, while another Lagos listing shows a 300kg S load cell at ₦40,000. These listings indicate that the market price can vary by supplier and specification.



For the latest 300kg S-Type Load Cell Price in Nigeria, buyers should confirm the exact model, specifications, warranty and stock availability before purchasing.



300kg S-Type Load Cell Price Range



Based on current Nigerian listings, an indicative price range is:



₦40,000 – ₦70,000



Premium, certified or specialized 300kg S-Type load cells may cost more depending on the brand, accuracy class, material and protection rating.



300kg S-Type Load Cell Key Features



Common features of a 300kg S-Type load cell include:



– 300kg rated capacity

– S-beam/S-type construction

– Tension and compression measurement

– Strain-gauge sensing technology

– Alloy-steel construction on many models

– Compact industrial design

– Suitable for weighing and force-measurement systems

– High sensitivity

– Available with different accuracy classes

– Available with weather-resistant protection ratings

– Suitable for connection to weighing indicators and signal-processing equipment



For example, a YZC-516 300kg S-Type specification lists alloy steel construction, 350Ω output impedance, 5–12V DC minimum/maximum excitation of 12V, IP66 protection and an M12 thread.



What Is a 300kg S-Type Load Cell?



A 300kg S-Type load cell is a force sensor designed to measure mechanical force through strain gauges. Its S-shaped structure allows it to measure both tension and compression, making it useful in different weighing and force-measurement applications.



Some 300kg S-Type models are specifically designed for crane scales, hopper scales, silo weighing, belt scales and other industrial weighing systems.



Uses of 300kg S-Type Load Cell



The 300kg S-Type load cell can be used for:



– Crane scales

– Hopper weighing systems

– Tank weighing

– Silo weighing

– Platform weighing systems

– Belt scales

– Blending systems

– Industrial weighing machines

– Material-testing equipment

– Force measurement

– Suspended weighing systems

– Process-control applications



The S-Type design is particularly useful where the sensor needs to measure either pulling or pushing forces.



Benefits of 300kg S-Type Load Cell



Accurate Weight Measurement



A quality load cell converts mechanical force into a small electrical signal that can be processed by a weighing indicator or suitable signal-conditioning electronics.



Tension and Compression Measurement



Unlike load cells designed only for one loading direction, S-Type designs can be configured for both tension and compression measurement.



Versatile Industrial Application



The 300kg capacity makes this type of sensor suitable for small and medium-capacity weighing applications.



Compact Construction



S-Type load cells are generally compact and can be installed in systems where space is limited.



Durable Construction



Many industrial models use alloy steel, while stainless-steel versions are also available for environments requiring greater corrosion resistance.



300kg S-Type Load Cell Compatibility



Before buying a 300kg S-Type load cell, ensure that it is compatible with your weighing indicator, amplifier, transmitter or ADC system.



Check:



– Rated capacity

– Rated output/sensitivity

– Excitation voltage

– Input resistance

– Output resistance

– Accuracy class

– Protection rating

– Mounting-thread size

– Cable configuration

– Cable length

– Indicator/transmitter compatibility

– Mechanical mounting arrangement



The load cell itself produces a very small differential electrical signal, so appropriate signal amplification and high-resolution conversion are required for many electronic weighing systems.



300kg S-Type Load Cell Datasheet



Specifications vary between manufacturers. A representative 300kg S-Type load cell may have specifications such as:



Specification| Typical/Example Value

Load Capacity| 300kg

Sensor Type| S-Type

Measurement| Tension & Compression

Material| Alloy steel or stainless steel

Rated Output| Around 2.0mV/V on many models

Excitation| Commonly 5–12V DC

Accuracy| Model-dependent; C3 available

Protection| IP65–IP67 depending on model

Cable| Commonly 3–4m

Mounting| Model-dependent

Application| Weighing & force measurement



For example, KELI’s DEE-A 300kg model specifies 2.0mV/V sensitivity, 400Ω input resistance, 352Ω output resistance, a 3m cable, alloy-steel construction, IP65 protection and OIML/CE compliance.



Other manufacturers offer 300kg S-Type models with C3 accuracy, IP67 protection and 150% safe overload capacity.



Always request the exact manufacturer’s datasheet before installation because specifications differ between models.



300kg S-Type Load Cell vs Other Load Cells



Feature| 300kg S-Type| Single-Point Load Cell| Compression Load Cell

Capacity| 300kg| Model-dependent| Model-dependent

Tension Measurement| Yes| Usually no| Generally no

Compression Measurement| Yes| Yes| Yes

Typical Application| Hanging, hopper, crane & force systems| Platform scales| Tanks, silos & heavy systems

Installation| S-beam mounting| Platform mounting| Compression mounting

Design| S-shaped| Beam/platform style| Compression column/button



300kg S-Type Load Cell vs 500kg S-Type Load Cell



The main difference is rated capacity. A 300kg S-Type load cell is designed for loads up to its rated capacity, while a 500kg model is designed for a higher maximum rated load.



Choose the capacity according to the weighing system’s maximum expected load, including appropriate safety considerations. Do not select a higher-capacity sensor simply because it is available, as sensitivity and system resolution can also matter.



How to Choose the Right 300kg S-Type Load Cell



Before ordering, consider:



1. Capacity: Confirm that 300kg matches your application.

2. Accuracy: Choose an appropriate accuracy class.

3. Material: Alloy steel is common; stainless steel may be preferable for corrosive environments.

4. Protection: Consider IP65, IP66 or IP67 depending on the installation environment.

5. Output: Confirm compatibility with the weighing indicator.

6. Mounting: Check thread sizes and mechanical dimensions.

7. Cable: Confirm cable length and wiring configuration.

8. Certification: Consider OIML/CE requirements where applicable.



Where to Buy 300kg S-Type Load Cell in Nigeria



If you are searching for 300kg S-Type Load Cell Price in Nigeria, contact Nature Links Nigeria Limited for current pricing, availability and delivery arrangements.



Distributor, Supplier & Authorized Dealer: Nature Links Nigeria Limited

Call: 07049528019

WhatsApp: 09040054359

Shop Address: F1571 UP, Alaba International Market, Lagos, Nigeria

Delivery: Same-day delivery in Lagos

Shipping: Same-day shipping to other states in Nigeria



Before payment, ask the supplier to confirm the exact load-cell model, rated capacity, accuracy class, material, IP rating, cable configuration, datasheet and warranty.



Why Buy a 300kg S-Type Load Cell from a Reliable Supplier?



Load cells are precision measurement components, so buying the correct specification is important. A reputable supplier can help you verify the sensor’s capacity, electrical characteristics and compatibility with your weighing indicator.



For industrial installations, professional calibration and correct mechanical installation are also important for obtaining reliable readings.
