Yohako 60A Charge Controller Price in Nigeria

Nature Links Nigeria Limited is a supplier and dealer of solar charge controllers, Yohako solar accessories, inverters, batteries, and other solar power equipment in Nigeria. We supply solar products to customers across the country. Contact us to confirm the availability, specifications, and warranty of the Yohako 60A charge controller.

Overview of the Yohako 60A Charge Controller

The Yohako 60A charge controller is a solar power system component designed to regulate the electricity flowing from compatible solar panels to a battery bank. A correctly selected charge controller helps manage battery charging and protects the battery from unsuitable charging conditions within the controller’s supported operating limits.

The 60A rating refers to the controller’s rated charging-current capacity, but the actual supported solar array power and voltage depend on the model. Before purchasing a Yohako 60A charge controller, confirm whether it uses PWM or MPPT technology, its maximum PV input voltage, and the battery voltages it supports.

•

Yohako Charge Controller 60A Price in Nigeria

The Yohako charge controller 60A price in Nigeria depends on whether the model is PWM or MPPT, its supported battery voltage, maximum solar input, features, warranty, and current availability.

Indicative price range: ₦50,000–₦250,000.

This is a provisional budgeting estimate, not a live-verified quotation for a specific Yohako model. Actual prices may vary significantly between PWM and MPPT versions. Contact Nature Links Nigeria Limited to confirm the current selling price and available model.

Factors that can affect the price include:

• Whether the controller uses PWM or MPPT technology.
• Maximum PV input voltage and supported solar array power.
• Supported battery voltages and battery chemistry.
• Display, monitoring, and protection features.
• Warranty coverage and supplier availability.

Uses of the Yohako 60A Charge Controller

The Yohako 60A charge controller may be used in compatible solar power installations for:

• Charging batteries from solar panels.
• Home solar systems with separate charge controllers.
• Small business and office solar installations.
• Off-grid solar power systems.
• Solar-powered lighting and other compatible DC applications.
• Battery charging arrangements where the solar array and battery bank match the controller’s specifications.

The controller does not generate electricity or replace an inverter. In an AC backup system, a compatible inverter is needed to convert battery DC electricity into usable AC power.

Benefits of the Yohako 60A Charge Controller

1. Regulated battery charging

A suitable controller regulates the charging process according to its design and configured battery settings.

2. Helps protect compatible batteries

When used correctly, supported charging and protection functions can help reduce the risk of unsuitable charging conditions.

3. Supports solar energy storage

The controller connects a compatible solar array to a battery-charging system, allowing generated solar energy to be stored for later use.

4. Suitable for different system designs

Depending on its specifications, a 60A controller can be used in various solar installations with appropriately sized panels and batteries.

5. Helps manage solar input

MPPT controllers can adjust their operating point to extract available power from the panels within their rated limits. PWM controllers operate differently and should not be assumed to deliver the same performance.

Datasheet and Buyer Checklist

Before buying a Yohako 60A charge controller, ask for the exact model datasheet and confirm these details.

Specification	What to check
Brand and model	Exact Yohako model number
Rated charging current	60A
Controller technology	PWM or MPPT
Battery voltage	Supported 12V, 24V, or 48V systems, as applicable
Maximum PV voltage	Must exceed the array’s operating requirements while remaining within the controller’s limit
Maximum PV power	Confirm the allowed array power for the selected battery voltage
Battery chemistry	Supported lead-acid or lithium battery types
Charging settings	Confirm voltage and current settings match the battery
Protection functions	Overcurrent, over-temperature, and other available protections
Monitoring	Display, indicators, or communication features, if provided
Warranty	Duration and service terms

Important: Do not select a solar array based on the 60A rating alone. The controller’s maximum PV voltage and permitted solar input power are equally important.

Compatibility with Solar Panels and Batteries

Solar panel compatibility

The solar array must match the controller’s input specifications. Panels connected in series increase voltage, while panels connected in parallel increase current. The final array configuration must remain within the controller’s voltage, current, and power limits.

Battery compatibility

Confirm that the controller supports your battery’s nominal voltage and chemistry. Lithium batteries may require specific charging settings and coordination with their battery management system (BMS).

Inverter compatibility

The controller can charge a compatible battery bank used with an inverter, but the inverter and controller must be suitable for the same battery voltage. The controller does not replace the inverter’s AC output function.

Wiring and protection

Use appropriately rated solar cables, connectors, fuses or circuit breakers, and isolators as required by the installation design. Have a qualified solar installer verify the wiring and protection.

Yohako 60A PWM vs MPPT Charge Controller

Feature	PWM controller	MPPT controller
Charging technology	Pulse-width modulation	Maximum power point tracking
Solar panel voltage	Array voltage must suit the battery-charging arrangement	Can use a higher PV voltage within its specified limits
Energy harvesting	Can be less effective when panel voltage differs substantially from battery voltage	Can convert available panel power more effectively under suitable conditions
Cost	Generally less expensive	Generally more expensive
System design	Often suited to simpler, appropriately matched systems	Often useful for larger or higher-voltage solar arrays
Key buying check	Confirm supported voltage and current	Confirm maximum PV voltage, current, and array power

Neither option is automatically right for every installation. Choose based on the solar array, battery bank, expected performance, and budget. Confirm which technology the Yohako model actually uses before ordering.

How Many Solar Panels Can a 60A Controller Support?

The number of panels depends on the controller’s technology, battery voltage, maximum PV voltage, and permitted solar input power. A 60A rating alone does not establish a universal panel count.

For illustration, the approximate output-side power associated with a 60A charging current is:

• 12V battery system: 60A × 12V = 720W nominal.
• 24V battery system: 60A × 24V = 1,440W nominal.
• 48V battery system: 60A × 48V = 2,880W nominal.

These are simplified calculations using nominal battery voltage, not guaranteed maximum solar input ratings. Actual charging voltage is higher than nominal battery voltage, and controller limits differ by model. Use the manufacturer’s specified PV power limits when designing the array.

Where to Buy a Yohako 60A Charge Controller in Nigeria

Nature Links Nigeria Limited supplies solar charge controllers and related solar power equipment in Nigeria. Contact the company to confirm the Yohako 60A charge controller’s current price, availability, technology, supported battery voltage, and warranty.

Distributor, Supplier and Dealer: Nature Links Nigeria Limited

Call: 07049528019

WhatsApp: 09040054359

Shop Address: F1571 UP, Alaba International Market, Lagos, Nigeria

Delivery: Same Day Delivery in Lagos. Same Day Shipping to Other States.

Ask for the exact model and datasheet before placing your order to ensure the controller suits your solar installation.
