Sale!

Water Cooling Tower 30tons

Name: Water Cooling Tower 30tons
Brand: 30 Ton Cooling Tower Nigeria
Availability: InStock

Original price was: ₦4,500,000.00.Current price is: ₦4,000,000.00.

Key Features of Water Cooling Tower 30 Tons

30TR nominal cooling capacity

FRP or other corrosion-resistant casing

Water collection basin

High-efficiency PVC honeycomb fills

Drift eliminators

Axial-flow fan

Electric fan motor

Water distribution system

Sprinkler or spray arrangement

Make-up water connection

Overflow and drain connections

Galvanized or corrosion-resistant hardware

Compact footprint

Low-maintenance construction

Suitable for industrial cooling applications

Click to See The Current Price! 🔥

Description
Reviews (0)

Description

Water Cooling Tower 30 Tons Price in Nigeria

Nature Links Nigeria Limited is an Authorized Distributor, Supplier & Dealer of genuine industrial cooling equipment in Nigeria, supplying water cooling towers, industrial chillers, cooling tower pumps, HVAC equipment and industrial cooling systems to customers across Nigeria.

Water Cooling Tower 30 Tons Price in Nigeria

The Water Cooling Tower 30 Tons Price in Nigeria depends on the tower design, cooling capacity, FRP or steel construction, fan and motor specification, PVC fill, water flow rate, basin configuration, brand, installation requirements and current importation costs.

For a 30-ton/30TR cooling tower, buyers should request a quotation based on the required operating conditions rather than relying only on the advertised price. Published specifications for 30TR towers show examples with approximately 300 L/min water circulation, 90,000 kcal/h cooling capacity, and a 1HP motor, although specifications vary considerably by design and operating conditions.

Water Cooling Tower 30 Tons Price Range in Nigeria

An indicative budget for a 30-ton water cooling tower in Nigeria is approximately ₦2,500,000 – ₦6,500,000+, depending on the manufacturer, tower construction, motor, fan, basin, fill material, accessories and whether installation is included.

30-Ton Cooling Tower Type| Indicative Price Range

Basic FRP 30TR Cooling Tower| ₦2,500,000 – ₦3,500,000

Standard Industrial 30TR Cooling Tower| ₦3,500,000 – ₦5,000,000

Heavy-Duty/Complete 30TR System| ₦5,000,000 – ₦6,500,000+

Note: These are indicative budgeting figures, not fixed quotations. The final price should be confirmed from the supplier according to the required cooling duty and configuration.

What Is a 30-Ton Water Cooling Tower?

A 30-ton water cooling tower, commonly referred to as a 30TR cooling tower, is a heat-rejection system used to remove heat from circulating water. Hot water enters the tower, comes into contact with moving air, and releases heat through evaporation and air movement before the cooled water is returned to the connected equipment.

A published 30TR FRP tower specification, for example, gives a capacity of 30TR, a water circulation rate of about 300 L/min and approximately 90,000 kcal/h cooling capacity.

Key Features of Water Cooling Tower 30 Tons

Important features can include:

– 30TR nominal cooling capacity

– FRP or other corrosion-resistant casing

– Water collection basin

– High-efficiency PVC honeycomb fills

– Drift eliminators

– Axial-flow fan

– Electric fan motor

– Water distribution system

– Sprinkler or spray arrangement

– Make-up water connection

– Overflow and drain connections

– Galvanized or corrosion-resistant hardware

– Compact footprint

– Low-maintenance construction

– Suitable for industrial cooling applications

A published 30TR model uses honeycomb PVC fills, an aluminium sprinkler, an axial-flow fan, TEFC motor, make-up and quick-fill arrangements, overflow/drain connections and a water-holding basin.

Uses of Water Cooling Tower 30 Tons

A 30-ton cooling tower can be used in:

– Industrial cooling systems

– Water-cooled chiller systems

– Plastic manufacturing

– Injection moulding plants

– Food-processing facilities

– Pharmaceutical manufacturing

– Chemical industries

– Manufacturing factories

– HVAC systems

– Compressor cooling

– Process-water cooling

– Commercial and industrial buildings

Cooling towers are particularly useful where equipment continuously produces heat that needs to be rejected efficiently.

Benefits of a 30TR Water Cooling Tower

Efficient Heat Rejection

The tower removes heat from circulating water using air and evaporative cooling.

Suitable for Industrial Applications

A 30TR capacity is suitable for many small-to-medium industrial cooling installations, although the actual required tower capacity must be calculated from the process heat load.

Corrosion Resistance

FRP construction is commonly used because it offers resistance to moisture and corrosion. Published 30TR FRP tower designs are specifically described as being suitable for harsh environments.

Compact Installation

Bottle-shaped and induced-draft designs can provide substantial cooling capacity without requiring an excessively large footprint.

Lower Energy Consumption

Properly selected cooling towers can achieve efficient heat rejection with relatively modest fan-motor power. One published 30TR model specifies a 1HP motor, although motor requirements vary according to tower design and operating conditions.

Water Cooling Tower 30 Tons Datasheet

The exact datasheet depends on the manufacturer and operating conditions. A representative 30TR tower may have specifications such as:

Specification| Typical/Example Value

Cooling Capacity| 30TR

Approx. Heat-Rejection Capacity| 90,000 kcal/h

Water Circulation| Approx. 300 L/min

Tower Type| FRP induced-draft

Fill Material| Honeycomb PVC

Fan| Axial-flow

Motor| Approx. 1HP on some models

Water Distribution| Sprinkler system

Basin| Integrated water-holding basin

Casing| FRP

Applications| Industrial/process cooling

One published 30TR model has dimensions of approximately 1,660 × 2,000 mm (diameter × height). However, dimensions and motor size should be confirmed against the selected manufacturer’s datasheet.

30TR Cooling Tower Compatibility

Before purchasing a 30-ton cooling tower, confirm compatibility with:

– Chiller capacity

– Condenser-water flow rate

– Entering water temperature

– Leaving water temperature

– Ambient wet-bulb temperature

– Required cooling range

– Approach temperature

– Pump capacity

– Water quality

– Electrical supply

– Available installation space

– Existing condenser-water piping

Cooling-tower selection should consider water circulation rate, inlet and outlet temperatures and ambient wet-bulb conditions.

30TR Cooling Tower for Chiller Systems

A 30TR cooling tower can be integrated into a water-cooled chiller installation. However, the cooling tower should not be selected solely because the chiller is rated at 30TR.

The tower must be sized according to the condenser heat rejection, condenser-water flow, entering and leaving water temperatures and local ambient conditions.

For example, published engineering specifications for a 30TR water-cooled chiller package specify a cooling tower with a water flow rate of 50 m³/hour, demonstrating why the required tower specification can differ substantially depending on the system design.

30TR Cooling Tower vs Air-Cooled System

Feature| 30TR Water Cooling Tower System| Air-Cooled System

Heat Rejection| Water + air| Air

Water Requirement| Required| Generally not required for heat rejection

Suitable Environment| Industrial/process cooling| Wide range of applications

Maintenance| Requires water treatment and cleaning| Mainly coil/fan maintenance

Footprint| Can be compact| May require larger condenser area

Efficiency| Can be highly efficient under suitable conditions| Depends heavily on ambient temperature

Application| Water-cooled chillers/process systems| Air-cooled chillers and equipment

30 Tons Cooling Tower Maintenance

Regular maintenance helps maintain cooling performance and extend equipment life.

Important maintenance tasks include:

– Cleaning PVC fills

– Inspecting the fan and motor

– Checking water distribution nozzles

– Cleaning the basin

– Checking drift eliminators

– Monitoring water quality

– Controlling scale and corrosion

– Checking pump performance

– Inspecting belts where applicable

– Checking vibration and unusual noise

– Cleaning debris from air passages

Proper water treatment is particularly important because mineral deposits, corrosion and biological growth can reduce cooling-tower efficiency.

What Determines the Water Cooling Tower 30 Tons Price in Nigeria?

The final Water Cooling Tower 30 Tons Price in Nigeria can be affected by:

– Brand and country of manufacture

– FRP or steel construction

– Cooling capacity

– Fan and motor size

– PVC fill quality

– Basin design

– Water distribution system

– Pump inclusion

– Control panel

– Piping and valves

– Installation

– Transportation

– Importation costs

– Exchange-rate fluctuations

– Warranty and after-sales support

A complete cooling-tower package with pump, controls, piping and installation will naturally cost more than the tower body alone.

Where to Buy Water Cooling Tower 30 Tons in Nigeria

Nature Links Nigeria Limited supplies industrial cooling equipment and can assist customers seeking a 30TR water cooling tower for factories, HVAC installations, chillers and process-cooling applications.

Distributor, Supplier & Authorized Dealer: Nature Links Nigeria Limited

Call: 07049528019

WhatsApp: 09040054359

Shop Address: F1571 UP, Alaba International Market, Lagos, Nigeria

Delivery: Same Day Delivery in Lagos. Same Day Shipping to Other States.

Contact Nature Links Nigeria Limited for the latest Water Cooling Tower 30 Tons Price in Nigeria, specifications, availability, delivery and installation requirements.

Water Cooling Tower 30 Tons Price in Lagos

The Water Cooling Tower 30 Tons Price in Nigeria can differ between suppliers in Lagos because of brand, stock availability, configuration and transportation requirements. Customers buying for industrial projects should provide their required water flow rate, inlet temperature, outlet temperature and ambient wet-bulb temperature to obtain a more accurate quotation.

How to Choose the Right 30TR Cooling Tower

When buying a 30TR cooling tower, do not focus on price alone. Confirm the manufacturer’s cooling performance at your actual site conditions.

A professional supplier should be able to assess:

1. Required cooling capacity

2. Condenser-water flow

3. Entering-water temperature

4. Leaving-water temperature

5. Ambient wet-bulb temperature

6. Cooling range

7. Approach temperature

8. Fan and motor requirements

9. Water-treatment requirements
